1.5 to 6 Ton Height Efficient Material Handling Diesel Forklift Truck
This forklift truck offers affordable pricing and customizable features for increased efficiency and convenience. With a lifting capacity ranging from 1.5 to 6 tons and a durable diesel engine, you can easily handle and transport materials without breaking the bank. Plus, with CE certification and a lifting height designed to meet your specific needs, this is a smart investment for any material handling operation. And with free shipping until 2024, there's never been a better time to upgrade your equipment.
Product descriptions from the supplier
Product Paramenter
| 1 | Model | CPCD20 | CPCD25 | CPCD30 | |
| 2 | Power Type | Diesel | Diesel | Diesel | |
| 3 | Rated Capacity | kg | 2000 | 2500 | 3000 |
| 4 | Load Centre | mm | 500 | 500 | 500 |
| 5 | Lift Height | mm | 3000 | 3000 | 3000 |
| 6 | Fork Size LxW*T | mm | 1070x120x40 | 1070x120x40 | 1070x120x45 |
| 7 | Mast Tilt Angle F/R | Deg | 6°/12° | 6°/12° | 6°/12° |
| 8 | Front Overhang (Wheel center to fork face) | mm | 465 | 465 | 480 |
| 9 | Ground Clearance (Bottom of mast) | mm | 110 | 110 | 140 |
| 10 | Length to face offork(Without fork) | mm | 2595 | 2595 | 2730 |
| 11 | Overall Width | mm | 1150 | 1150 | 1225 |
| 12 | Overall Dimension Mast Lowered Height | mm | 2070 | 2070 | 2115 |
| 13 | Mast Extended Height(With backrest) | mm | 4070 | 4070 | 4150 |
| 14 | Overhead Guard Height | mm | 2070 | 2070 | 2090 |
| 15 | Turning Radius (outside) | mm | 2310 | 2310 | 2440 |
| 16 | Min insecting aisle | mm | 2380 | 2380 | 2490 |
| 17 | Speed Travel (Empty load) | km/h | 19 | 19 | 20 |
| 18 | Speed Lifting(Full load) | mm/s | 530 | 530 | 510 |
| 19 | Max.Gradeability | % | 20 | 20 | 20 |
| 20 | Tire Front | mm | 7.00-12-12 PR | 7.00-12-12 PR | 28 x9-15-12 PR |
| 21 | Tire Rear | mm | 6.00-9-10 PR | 6.00-9-10 PR | 6.50-10-10 PR |
| 22 | Wheelbase | mm | 1600 | 1600 | 1700 |
| 23 | Service weight | kg | 3590 | 3790 | 4300 |
| 24 | Battery Voltage/Capacity | V/Ah | 12/80 | 12/80 | 12/80 |
| 25 | Model | C240 | S4S | C240 | |
| 26 | Manufacture | ISUZU | MITSUBISHI | ISUZU | |
| 27 | Engine Rated output/r.p.m. | kw | 35.4/2500 | 38/2300 | 35.4/2500 |
| 28 | Engine Rated torque/r.p.m. | N-m | 137.7/1800 | 176/1800 | 137.7/1800 |
| 29 | Engine No.of Cylinder | 4 | 4 | 4 | |
| 30 | Engine BorexStroke | mm | 86 x 102 | 94 x 120 | 86 x 102 |
| 31 | Engine Displacement | cc | 2369 | 4400 | 2369 |
| 32 | Engine Fuel Tank Capacity | L | 60 | 60 | 60 |
| 33 | Transmission Type | Hydraulic | Hydraulic | Hydraulic | |
| 34 | Transmission Stage FWD/RVS | 1/1 | 1/1 | 1/1 | |
| 35 | Transmission Operating Pressure for Attachment | Mpa | 18 | 18 | 18 |
